CPCD120-C1Z-09ⅢG
Rated Capacity: 12 ton
Load center distance：900mm
Power: Diesel

  • Features:











    Applications: As lifting and transporting machineries, Wings G series Balance Weight Type Forklift trucks are widely used for loading, unloading and transporting the packaged goods in factories, warehouses, stations, wharves, ports and so on. The fork lift truck can also be used for bulk goods and unpacked good loading, unloading and handing after assembled with other attachments.


  • Specification

    CPCD120-C1Z-09ⅢG
    Technical parameters
    Rated loadt12
    Maximun lifting speed(loaded/unloaded)mm/s360/400
    Maximun speed(loaded/unloaded)km/h25/27
    Gradeability(loaded/unloaded)%36.4%/40%
    Noise in the cabdB(A)≤73.8
    Size parameters
    Overall lengthmm6705
    Overall widthmm2560
    Overall heightmm3365
    Load center distancemm900
    Wheelbasemm3250
    Minimum underground clearancemm260
    Seat heightmm1970
    Turning radius(outside)mm4450
    Front trackmm1888
    Rear trackmm2120
    Mast height(retracted/extended)mm3365/4865
    Mast lifting heightmm3000
    Mast tilting angle(forward/backward)deg6/12
    Fork dimension(length*width*thickness)mm1820×200×85
    Fork adjusting rangemm500-2370
