CPCD160-C1Z-06ⅢG
Rated Capacity: 16 ton
Load center distance：600mm
Power: Diesel

  •   Features:



    Applications: As lifting and transporting machineries, Wings G series Balance Weight Type Forklift trucks are widely used for loading, unloading and transporting the packaged goods in factories, warehouses, stations, wharves, ports and so on. The fork lift truck can also be used for bulk goods and unpacked good loading, unloading and handing after assembled with other attachments.



  • Specification

    CPCD160-C1Z-06ⅢG
    Technical parameters
    Rated loadt16
    Maximun lifting speed(loaded/unloaded)mm/s350/400
    Maximun speed(loaded/unloaded)km/h26/28
    Gradeability(loaded/unloaded)%36.4%/40%
    Noise in the cabdB(A)≤73.8
    Size parameters
    Overall lengthmm6265
    Overall widthmm2560
    Overall heightmm3380
    Load center distancemm600
    Wheelbasemm3250
    Minimum underground clearancemm250
    Seat heightmm1985
    Turning radius(outside)mm4500
    Front trackmm1888
    Rear trackmm2120
    Mast height(retracted/extended)mm3380/4880
    Mast lifting heightmm3000
    Mast tilting angle(forward/backward)deg6/12
    Fork dimension(length*width*thickness)mm1370×200×85
    Fork adjusting rangemm500-2370
