Wheel Loader ZL60
Rated Load: 6000kg
Bucket Capacity:3.3-3.5m³
Weight: 20000kg

  • Features:

    1.Stronger frame design for heavy duty, which makes the loader’s usage life longer.

    2.It is fixed with Weichai 240hp engine, which features high power reserve, high torque, strong power, low fuel consumption, high quality, low emission and high reliability.

    3.ZL60G gearbox is adopted with front 4 and rear 4 gear positions to render better transmission efficiency and larger transmission ratio of forward positions 1 and 2 owing to the one additional position, and its comprehensive efficiency is increased by over 8%。

    4.The new generation cab is adopted with space increased by 15% to enhance safety and comfort. The attractive curved front windshield provides a broad view

    5.The engine hood and heat dissipation hood adopt the large opening design to provide larger space for maintenance.

    6.Optional multiple attachments, including: multiple buckets, pallet fork, handing arm, grapple and snow blade greatly expands the applications of the wheel loader.




  • Specification

    		Brand
    		WINGS

    		Model
    		ZL60
    PerformanceLoader Lifing Capacitykg6000
    Operating Weightkg20000
    Rated Bucket Capacitym³3.3-3.5
    Max. Tractive Forcekn172
    Max. Breakout Forcekn183
    Max. Grade Ability°30°
    Max. Dump Heightmm3048
    Max. Dump Reachmm1480
    Overall Dimension(L×W×H)mm8414×3370×3458
    Min. Turning Radiusmm6500
    EngineModelmmWeichai Steyr Engine
    TypemmInline, water cooled, four stroke
    Cylinder-Inner Diameter*Strokemm6-126×130
    Rated Powerkw175
    Max. TorqueN.m998
    Min. Fuel-sonsume ratiog/kw.h220
    Transmission
    System    		Torque Converter
    		YJ315
    Gearbox Mode
    		Countershaft power shift
    Gears
    		2 forward and 1 reverse gears/
    4 forward and 4 reverse gears
    Max. Speedkm/h38
    Drive AxlesWheel Basemm3350
    Wheel Treadmm2250
    Ground Clearancemm450
    Hydraulic
    System    		System Working Pressurempa18
    Boom Lifting Times5.3
    Total Times9.7
    Fuel Tank CapacityL300
    Self-Levelling
    		yes
    Brake
    System    		Service Brake
    		Dry&caliper, air to oin
    control
    Parking Brake
    		Brake,sprin applied&oil
    released
    TyreTyre Model
    		26.5-25
    Front Tyre PressureMpa0.4
    Rear Tyre PressureMpa0.35
